| 型号models | LLN－910 | LLN－1140 | LLN－1430 | LLN－2040 | LLN－2160 |
合模力 MN Mould clamping force | 0.30 | 0.50 | 0.85 | 1.80 | 2.25 |
联杆内侧公称间距mm Normal space between two side links | 910 | 1140 | 1430 | 2040 | 2100 |
模型最大高度 mm Max. height of the mould | 320 | 380 | 450 | 790 | 820 |
模型最小高度 mm Min. height of the mould | 250 | 310 | 360 | 440 | 440 |
模型开闭时间 S Open and close mould time | ≤5 | 5 | 10 | 19 | 17 |
输入内胎的饱和蒸汽压力 Mpa Saturated steam pressure of the tube | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ≤0.8 |
输入模型内的饱和蒸汽压力 Mpa Steam pressure of the mould inlet | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ≤0.8 |
驱动电动机功率 KW Motor power | 4 | 5.5 | 5.5 | 11 | 11 |
驱动电动机转速 r/min Motor speed | 960 | 960 | 960 | 960 | 730 |
外形尺寸 mm Overall dimention(L x W x H) | 2170×1500×1615 | 2457×1670×2009 | 2710×2210×2060 | 3450×2650×3360 | 2850×2700×2700 |
