适用外胎种类 Applicable types of tyres | 摩托车轮胎 Mobike tyres | 摩托车轮胎 Mobike tyres |
规格 Specification | 8″-21″ | 4″-12″ |
模型数量 No. of molds | 2-4 | 2-4 |
总压力（每个模型） Total pressure (each mold) (Mpa) | 100 | 60 |
液压系统压力设定值 Hydraulic system pressure setting (Mpa) | ≤21 | ≤21 |
液压工作压力设定值 Hydraulic working pressure setting (Mpa) | ≤19.5 | ≤19.5 |
热板直径 Dia. of hot plate (mm) | 950 | 650 |
保温罩内径 Inner dia. of insulation cover (mm) | Φ975 | Φ700 |
最大热板间距 Max. clearance between plates (mm) | 1000 | 1000 |
适用模具高度 Applicable mold height (mm) | 120-300 | 120-300 |
生胎最大厚度 Max. thickness of green tyre (mm) | 450 | 450 |
脱模力 Demolding force (k) | 750 | 750 |
最大顶胎高度 Max. height of the top tire (mm) | 200 | 200 |
开（合）模速度 Open (close) mold speed (mm/s) | 60 | 60 |
热板加热蒸汽压力 Hot plate heating steam pressure (Mpa) | Max.1.0 | Max.1.0 |
内压蒸汽或压缩空气压力 Inner pressure steam or compressed air pressure (Mpa) | 1.5-2.3 | 1.5-2.3 |
定型蒸汽或压缩空气压力 Shaping steam or compressed air pressure (Mpa) | 0.1-0.2 | 0.1-0.2 |
水（气）缸用压力 Water (gas) cylinder use pressure (Mpa) | 1.5-2 | 1.5-2 |
控制用压缩空气压力 Controlling use compressed air pressure (Mpa) | 0.35 | 0.35 |
真空度 Vacuum (Mpa) | 0.013-0.026 | 0.013-0.026 |
液压油 Hydraulic oil | 46#anti-wear hydraulic oil | 46#anti-wear hydraulic oil |
油泵电机 Pump motor (kw) | Y180L-4-22 | Y180L-4-22 |
机器总重量 Total weight (kg) | 11500 | 9500 |
