After friction, cutting the curtain fabric, canvas, viboud into given width and angle,and after cutting, all the fabric will be connected and rolled for using.
After friction, cutting the curtain fabric, canvas, viboud into given width and angle,and after cutting, all the fabric will be connected and rolled for using.
每分钟裁刀次数 Cutting times per minute | 10-20 |
适用帘布门幅 Applicable cord width (mm) | 1500 |
帘布卷直径 Dia. of fabric cord roll (mm) | 950 |
裁布宽度 Cloth cutting width (mm) | 100-1000 |
裁布角度 Cloth cutting angle (°) | 0-50 |
裁刀行程 Stroke of cutter (mm) | 2800 |
定长方式 Length fixing type | 手动或自动 Manual or automatic |
裁刀转速 Revolving speed of cutter (r/min) | 5700 |
压缩空气压力 Pressure of compressed air (Mpa) | 0.6-0.8 |
总容量 Total capacity (kw/h) | 10 |
外形尺寸 Overall dim. (LxWxH) (mm | 10500x4300x2100 |
重量 Weight (kg) | 4500 |
